Product Features:

● Non-contact, portable design, adjustable model, a machine:
The use of photographic style principle, non-contact 3D optical scanning, three-dimensional data obtained surface. And adapted to the soft, deformable object measurement requirements, equipment, hardware size, small footprint, no noise, can be easily brought to the measurement site, you can also move the scanning device when scanning large heavy objects;
● High measurement accuracy:
Strong ability to capture the details of the measurement accuracy up to 0.02mm ~ 0.05mm;
● Measurement speed:
Single Scan time <= 5 seconds, the measurement pitch cloud data very regular;
● measuring large depth of field:
Depth range of 300 ~ 500mm;
● wide scan range:
Can scan small objects a few millimeters to several meters large scanning range can be freely chosen, suitable for different size products scan;
● marker automatic stitching:
Intelligent integration of single point cloud; scanning the test object can be moved to any flip through the stitching on the sign points to the measured data to form three-dimensional measurement of objects in order to achieve full-body scanning, reducing the dead and blind scan measurements;
● High resolution:
High-density point cloud data, fine parts of objects can be clearly delineated;
● PTS ? system global error control
● low demand on the environment:
Not much affect the normal ambient light of the scanning system, under normal ambient light can get high-quality office;
● self-development, and manufacturing, independent software intellectual property:
Developed and manufactured its own, independent software intellectual property protection software continue free upgrades, professional R & D team to provide service 24 hours a machine that can be customized according to customer demand;
● Lifetime upgrade:
Security software constantly free upgrade for future higher level and update requirements;
● Simple operation:
One-button scanning, without too much training (2-3 days) that can skillfully operate;
● measuring the output data interface rich:

The measured point cloud data as ASC, STL, PLY, IGES, OBJ, DXF, etc., can be directly related Surfacer, image ware, UG, CATIA, Geomagic, Pro / E, Master CAM software for data exchange.

Models and technical specifications:

Model	PTS-400H integrated
Scanning	Non-contact surface scan
Single scan range (mm2)	100×75～200×150～400×300
The maximum measuring range (mm3)	2000×1500×1500
Accuracy (mm)	0.02～0.05
Single sweep points (pixels)	1,300,000×2
Single scan speed	<5S
Average Pitch (mm)	0.05～0.3
Output file formats	ASC,IGES, STL, VRML, DXF ,etc.
Splicing	Mark point automatic stitching, intelligent integration of single point cloud
Operating system	Windows2000 / XP / Vista

PTS ? camera three-dimensional scanner (scanner machine) can be widely used:
● footwear
● Mould Manufacturing
● Industrial Design
● Toy Design
● Body and ship design
● Product error detection and assessment
● teaching application (reverse engineering)
● castings scan measurements
● ceramic sanitary
● styling appliances
● underwear mold making
● Conservation and data scanning
● Aerospace Industry
● areas of wood / stone carving, measuring small objects to a few millimeters to tens of meters to meters large, unlimited measurement space has important commercial value.
